Class Avogadro::Rendering::Drawable#

class Drawable#

The base class for all drawable geometry and types.

This class provides the common API for drawable objects on the scene. It is not a Node object, and can only be attached to GeometryNode objects in the Scene.

Author: Marcus D. Hanwell

Subclassed by AmbientOcclusionSphereGeometry, ArrowGeometry, CurveGeometry, CylinderGeometry, DashedLineGeometry, LineStripGeometry, MeshGeometry, SphereGeometry, TextLabelBase, VolumeGeometry

Unnamed Group

inline void setRenderPass(RenderPass pass)#

The render pass in which this drawable should be rendered.

See also

Rendering::RenderPass

Public Functions

Drawable()#

Drawable(const Drawable &other)#

virtual ~Drawable()#

inline Drawable &operator=(Drawable)#

virtual void accept(Visitor&)#: Accept a visit from our friendly visitor.

inline const GeometryNode *parent() const#

Get a pointer to the drawable object’s parent.

Returns:: Pointer to the parent node, nullptr if no parent.

inline GeometryNode *parent()#

inline void setVisible(bool visibility)#

Set the visibility of the drawable object.

Parameters:: visibility – True if the drawable is visible, false if invisible.

inline bool isVisible() const#

Get the current visibility of the drawable.

Returns:: True if visible.

virtual void render(const Camera &camera)#

Render the contents of the drawable.

Parameters:: camera – The current Camera.

inline Identifier &identifier()#: Get the identifier for the object, this stores the parent Molecule and the type represented by the geometry.

inline const Identifier &identifier() const#

virtual std::multimap<float, Identifier> hits(const Vector3f &rayOrigin, const Vector3f &rayEnd, const Vector3f &rayDirection) const#

Return the primitives that are hit by the ray.

Parameters:

rayOrigin – Origin of the ray.
rayEnd – End point of the ray.
rayDirection – Normalized direction of the ray.

Returns:

Sorted collection of primitives that were hit.

virtual Core::Array<Identifier> areaHits(const Frustrum &f) const#

Return the primitives within the supplied area.

Parameters:: f – The frustrum defining the area highlighted.
Returns:: Collection of primitives in the area.

virtual void clear()#: Clear the contents of the node.

Protected Functions

void setParent(GeometryNode *parent)#

Set the parent node for the node.

Parameters:: parent – The parent, a value of nullptr denotes no parent node.

Protected Attributes

GeometryNode *m_parent#

bool m_visible#

RenderPass m_renderPass#

Identifier m_identifier#

Friends

friend class GeometryNode

friend void swap(Drawable &lhs, Drawable &rhs)#
